Rev.0 13/01/2020
Operator Panel | TURNTABLE - MAST
20
DA N G ER
The cycle “up only or down only” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic cycle which wrapp the pallet starting from the bottom to
reach the top or starting from the top to reach the bottom.
During winding, buttons
(B)
(carriage going up) or
(G)
down) can be pressed to stop the carriage, add extra wrapp wherever
required, and start it again.
Automatic cycle that wraps the pallet starting from a preset height
which is set with the
F10
function.
Automatic cycle that wraps the pallet stopping at a preset height which
is set with the
F11
function.
Automatic cycle that can be used when the machine is equipped with
the optional presser.
F21 = 1 ENABLED F21 = 0 DISABLED
Once the start cycle button has been pressed
(A)
signals five seconds in advance that the presser plate is going to
descend.
-
After the audible warning time has elapsed, the presser descends until it
is in contact with the top of the product. The function
F25
of the descent to adjust the pressure on the product.
-
The table begins to turn and the wrapping phase of the product on
the pallet starts.
-
At the end of the cycle the turntable stops and the presser plate
returns upwards, leaving the product free for unloading.
To manually control the ascent and descent of the pressure unit the
Functions display needs be set to
F21
(which needs to be set to
1
Value) and press button
(B)
for ascent or button
(G)
for descent.
See Picture 8 - pag. 19
