Atlanta EVA - CONTROLS DESCRIPTION

Rev.0 13/01/2020
Operator Panel | TURNTABLE - MAST
4
1.1.4
A
Programmed cycle START button.
B Carriage up manual retention button.
If pressed together with (E)
, the presser automatically rises to
the up cycle start position.
C Decrease values button.
D Increase values button.
E Alarm reset (fast pressure – less than 2 second);
Saving parameters (press until the LED flashes - more than 3
seconds);
When pressed along with the STOP
button, it stops and resets
the cycle (the display (V) shows INI to show the cancellation).
F
2-digit display indicating the functions (parameters) of the
selected programme;
During the cycle it shows the current operating status;
CF on the display (V)
at the end of the cycle means the film is
depleted;
AA on the display (V) means there is an alarm on the machine.
G
Carriage down manual retention button (if pressed together
with (E)
, the carriage automatically descends to the low cycle
start position).
H
Rotating arm manual, hold down to stop the rotating arm in
phase (if pressed together with “E” the table automatically turns
to the phase position).
O STOP
cycle pause button, the rotating arm decelerates and
stops, the cycle can be resumed from the same point.
P 2-digit display showing the selected programme;
During the cycle it shows an animation of the rotation of the
platform;
NOTE
: the flashing display indicates that a parameter has been
changed).
V 3-digit display indicating the value of the displayed function;
During the cycle or manually moving the film carriage, it indicates
the current height;
The central and left points are decimal points for the values.
When the right point is lit, the V+ and V-
keys are blocked and
the parameter values cannot be changed.
