The Atlantic Fountain Basin Plumbing Kit (Part No. FBKIT3) is a comprehensive solution designed to facilitate the proper installation and operation of fountain features within Atlantic's Pro Series Fountain Basins, specifically the FB4600 model, and with some modifications, the FB3200 model. This kit is engineered to integrate seamlessly with TidalWave 2 pumps, ensuring efficient water management for various decorative water features such as urns, columns, or drilled boulders.

Function Description:

The primary function of the FBKIT3 is to provide all the necessary plumbing components to connect a pump to multiple fountain outlets within a basin, manage water flow, and accommodate electrical cords. It streamlines the installation process by bundling essential fittings, tubing, and sealants, eliminating the need to source individual components. The kit ensures a clean and organized setup, allowing for easy maintenance and reliable performance of the fountain system.

Important Technical Specifications and Components:

TW2 Pump Discharge Fittings: These fittings are specifically designed to connect to Atlantic's TidalWave 2 pumps. The kit includes fittings compatible with both the TW1900 & TW2400 pumps, as well as the TW3700 & TW4800 pumps. For the TW3700 or TW4800, the pump's supplied threaded coupling must be removed to accept the 1-1/2" female thread adaptor included in the kit.
Triton 3-Way Manifold: This central component allows for the distribution of water from a single pump to up to three separate fountain outlets. Its design facilitates organized plumbing within the basin's channels.
20' of 3/4" Diameter Kink-Free Hose: This flexible tubing is crucial for routing water from the manifold to the individual fountain features. Its kink-free property ensures unobstructed water flow and durability. The tubing needs to be cut to length on-site, providing flexibility for various fountain configurations.
3 Piece Standpipe Sealant: This EPDM-based sealant is used to create a watertight seal around the standpipes where they enter the 3/4" elbows. Its pliable nature allows for easy application and reuse, ensuring long-term sealing integrity.
(3) 3/4" Insert x 3/4" Socket Fittings: These elbow fittings connect the kink-free hose to the standpipes of the decorative fountain items. The barbed end inserts into the hose, while the socket end receives the standpipe.
(2) 1-1/2" Cord Stoppers for Conduit Sleeves: These stoppers are designed to plug the top of the 1-1/2" conduit sleeves, preventing gravel and other debris from entering the conduits. This protects pump cords and low voltage wiring routed through the sleeves.
Additional Fittings: The kit also includes various other fittings such as a 1-1/2" MTA (Male Thread Adaptor), 2" Fernco coupling, 1-1/2" 45-degree elbow, 1-1/2" PVC coupling, 1-1/2" Street 90 & 1-1/2" Male Adaptor, and 1-1/2" Street 90 & 1-1/2" Female Adaptor. These provide comprehensive options for connecting the pump to the manifold and ensuring proper water flow.

Usage Features:

Versatile Compatibility: While primarily designed for the FB4600 Fountain Basin, the kit can be adapted for use with the FB3200 Fountain Basin. For the FB3200, the Triton 3-way manifold must be installed inside the pump chamber, requiring removal of the pump cover for access. Additionally, the FB3200 comes with one predrilled hole for a feed line up to 1" in diameter, and additional holes may need to be drilled on-site for multiple feed lines, with drill points provided by the factory.
Organized Plumbing: The kit's components, particularly the Triton 3-way manifold and the basin's plumbing channels, promote an organized and concealed plumbing setup. This enhances the aesthetic appeal of the fountain and simplifies troubleshooting.
Customizable Tubing Length: The 20' of kink-free hose allows installers to cut the tubing to the precise length required for each fountain outlet, accommodating various decorative item placements and basin sizes.
Easy Standpipe Connection: The 3/4" insert x 3/4" socket fittings provide a straightforward connection point for the fountain's standpipes, ensuring a secure and leak-free interface.
Conduit Management: The inclusion of cord stoppers for conduit sleeves highlights the kit's attention to detail in managing electrical cords. This feature protects wiring from environmental elements and debris, contributing to the longevity and safety of the electrical components.
Clear Installation Instructions: The manual provides a step-by-step guide with diagrams, making the installation process clear and manageable for users.

Maintenance Features:

Reusable Standpipe Sealant: The EPDM-based standpipe sealant is designed to remain pliable, allowing for easy removal and reuse if maintenance or adjustments to the standpipes are required. This reduces waste and simplifies future work.
Protected Wiring: The cord stoppers for the conduit sleeves prevent debris from entering, which protects pump cords and low voltage wiring from damage, thereby reducing the need for repairs or replacements.
Durable Components: The use of kink-free hose and robust fittings ensures the longevity of the plumbing system, minimizing the frequency of maintenance.
Accessible Manifold (FB3200): Although the manifold is installed inside the pump chamber for the FB3200, the design allows for access by removing the pump cover, facilitating any necessary adjustments or repairs.

In summary, the Atlantic Fountain Basin Plumbing Kit FBKIT3 is a well-thought-out and comprehensive solution for installing fountain features. It provides all the necessary components for efficient water distribution, organized plumbing, and protection of electrical wiring, ensuring a reliable and aesthetically pleasing water feature.
