Atlas Copco FlexiROC T30 R

FlexiROC T30 R 10 Hydraulic System
64 No: 3629357835.1.3629419915 en-US
10.7 Hydraulic Tank
10.7.1 Check Hydraulic Tank
Precondition
p
The machine is parked on a flat and leveled surface.
p
The oil temperature is 40°C / 104°F.
n
Replace the return oil filter (A) if the warning sign is displayed.
n
Check the breather filter (B).
n
Check the tank (C) and connections for signs of leakage.
n
Check that the oil level covers the lower sight glass (D) and half of the upper sight
glass (E).
10.7.2 Drain Water Condensation from Hydraulic Oil Tank
