7.5 bar 8.5 bar 10 bar 13 bar 100 psi 125 psi 150 psi 175 psi
Oil capacity, air-cooled
units
Imp gal 3.43 3.43 3.43 3.43 3.43 3.43 3.43 3.43
Oil capacity, water-
cooled units
l 17.9 17.9 17.9 17.9 17.9 17.9 17.9 17.9
Oil capacity, water-
cooled units
US gal 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73
Oil capacity, water-
cooled units
Imp gal 3.94 3.94 3.94 3.94 3.94 3.94 3.94 3.94
Sound pressure level
(according to ISO 2151
(2004))
dB(A) 69 69 69 69 69 69 69 69
GA 37
+
7.5 bar 8.5 bar 10 bar 13 bar 100 psi 125 psi 150 psi 175 psi
Frequency Hz 50 50 50 50 60 60 60 60
Maximum (unloading)
pressure, Workplace
units
bar(e) 7.5 8.5 10 13 7.4 9.1 10.8 12.5
Maximum (unloading)
pressure, Workplace
units
psig 109 123 145 189 107 132 157 181
Maximum (unloading)
pressure, Workplace
Full-Feature units
bar(e) 7.3 8.3 9.8 12.8 7.2 8.9 10.6 12.3
Maximum (unloading)
pressure, Workplace
Full-Feature units
psig 106 120 142 186 104 129 154 178
Reference working
pressure
bar(e) 7 8 9.5 12.5 6.9 8.6 10.3 12
Reference working
pressure
psig 102 116 138 181 100 125 150 175
Pressure drop over
dryer, Workplace Full-
Feature units
bar(e) 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13
Pressure drop over
dryer, Workplace Full-
Feature units
psig 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9
Set point of thermostatic
valve
˚C 40 40 40 60 40 40 40 60
Set point of thermostatic
valve
˚F 104 104 104 140 104 104 104 140
Motor shaft speed r/min 2956 2956 2956 2956 3565 3565 3565 3565
Nominal motor power kW 37 37 37 37 37 37 37 37
Nominal motor power hp 49.6 49.6 49.6 49.6 49.6 49.6 49.6 49.6
Instruction book
172 2920 7109 51
