60 575 5 8 12 - - - 4.5 8
(1): Motor circuit breaker with residual current device type D
GX 4 and GX 5
Frequency
(Hz)
Voltage (V) Overload
relay (IG),
GX 4 (A)
Circuit breaker,
GX 4 (A) (see note
1)
Overload
relay (IG),
GX 5 (A)
Circuit breaker,
GX 5 (A) (see note
1)
Circuit breaker,
dryer supply (A)
(see note 1)
IEC DOL Max.
capacity
Setting Max
capacity
Setting Max
capacity
Setting
50 230 19 20 20 - - - 6.3 2
50 400 11 16 11 - - - 6.3 2
60 200 19 20 19 - - - 6.3 2
60 380 11 16 11 13.5 16 13.5 6.3 2
IEC Y-D
50 200 - - - 25 32 25 6.3 2
50 230 19 20 20 23.5 25 23.5 6.3 2
50 400 11 16 11 13.5 16 13.5 6.3 2
60 200 - - - 25 32 25 6.3 2
Frequency
(Hz)
Voltage (V) Overload
relay (OL),
GX 4 (A)
Main fuses,
compressor
supply, GX 4 (A)
Overload
relay (OL),
GX 5 (A)
Main fuses,
compressor
supply, GX 5 (A)
Main fuses, dryer
supply (A)
cULus DOL Type J or
RK
Type
CC
Type J or
RK
Type
CC
Type J or
RK
Type
CC
60 200-208 21.2 30 - 24.7 40 - 4.5 8
60 230 18.2 30 - 22.5 40 - 4.5 8
60 230, 1-ph 30.8 60 - 41 60 - 4.5 8
60 460 9.1 12 25 11.4 15 25 4.5 8
60 575 7.5 10 15 9.5 12 20 4.5 8
(1): Motor circuit breaker with residual current device type D
GX 7
Frequency
(Hz)
Voltage (V) Overload
relay (IG),
GX 7 (A)
Circuit breaker,
GX 7 (A) (see note
1)
Circuit breaker,
dryer supply (A)
(see note 1)
IEC Y-D Max
capacit
y
Setting
50 230 19.1 32 31.5 6.3 2
50 400 11 20 18 6.3 2
60 380 11 20 19 6.3 2
Instruction book
62 2920 7105 31
