Information label
A. Control lamp, charging.
B. Hour meter.
C. Control lamp, engine oil pressure.
Throttle control label
For standard throttle control.
Throttle control label
For EPA (US Environmental Protection Agency)
throttle control with three fixed positions.
Electrical engine start label
Transport
Lifting the machine
WARNING Lifting hazard
Never lift the machine without checking if it is intact.
A damaged machine can fall apart, which can result
in serious injury.
► Check that all equipment are dimensioned in
accordance with applicable regulations.
► Never tow the machine.
► Never walk or stand under a lifted machine.
► Only lift the machine by a hook on the frame.
► Check that the shock absorbers and safety frame
are correctly attached and not damaged.
► Check that the safety straps are not damaged,
change if necessary.
► Check the machine's data plate for weight
information.
Lifting the machine
♦
Before lifting the machine check that the shock
absorbers (A) and safety frame lifting point (B) are
correctly attached and not damaged.
♦
Only use the safety frame lifting point (B) for lifting
the machine.
15© 2016 Construction Tools EOOD | No. 9800 1721 01 | 2016-04-07
Original instructions
Safety and operating instructionsLG 504
