Parts Lists 38
BP8000
Parts For Hydraulic Cylinder
Item Part# Description Qty. Note
27-1 201027A Piston Rod 2
27-2 201028 Piston 2
27-3 206069 O-Ring 2
27-4 201029 Support Ring 2
27-5 201030 Y-Ring 2
27-6 201031 O-Ring 2
27-7 206071 Hex Nut 2
27-8 201037 Adjustment Tube 2
27-9 209078 Dust Seal 2
27-10 201032 O-Ring 2
27-11 201033 Head Cap 2
27-12 201034 Bleeding Plug 2
27-13 201035 O-Ring 2
27-14 201036A Bore Weldment 2
Parts For Hydraulic Power Units
Item Part# Description Qty. Note
201-1 81400152 Motor (ETL certifi cate) 1
201-2 81400209 Cover of Motor Terminal Box 1
201-3 81400252 Contactor 1
201-4 81400127 Motor Connecting Shaft 1
201-5 81100175 Relief Valve 1
201-6 81400210 Valve Body 1
201-7 81400143 Plug 1
