Atlas PV-10PX User Manual

PV-10PX and PV-10HPX Parts List 45
PV-10PX / PV-10HPX
PV-10PX and
PV-10HPX Parts List
Item Part# Description
Qty.
Note
PV-10PX PV-10HPX
1 217001B Powerside column 1 1
201 209002 Manual Power unit 1 1
3 209003 Hex Bolt 4 4
4 209033 Lock washer 24 24
5 209005 Self locking nut 8 8
6 217003 Powerside lock cover 1 1
7 217004 Main cam lock 1 1
8 217069 Hex Bolt 38 38
9 206006 Washer 35 35
10 206023 Self locking nut 34 34
11 420018 Self locking nut 8 8
12 217013 Hex Bolt 8 8
13 420045 Washer 30 30
14 61K074 Protective ring 2 2
15 217169 Right overhead bar 1 1
16 217170 Left overhead bar 1 1
17 420044 Pin stop 2 2
18 209149 Washer 4 4
19 420138 Socket Bolt 4 4
20 217019 Top pulley 4 4
21 217020 Bronze bush for pulley 6 6
22 217021 Top pulley spacer 4 4
23 217022 Pin 2 2
24 217023 Pin spacer 2 2
25 217024 Hose support 2 2
26 206009 Plastic small pulley 3 3
27 209056 Self locking nut 3 3
28 209046 Hex Bolt 3 3
29 217026 Safety cable bracket 2 2
30
217027
Extension column
20
217027A 0 2
