Atlas PV-10PX User Manual

PV-10PX andPV-10HPX Parts List 48
PV-10PX / PV-10HPX
Item Part# Description
Qty.
Note
PV-10PX PV-10HPX
98B 209247 Inner Arm – front 2 2
99 217321 Lifting Arm-rear 2 2
99A 209245 Middle Arm – rear 2 2
99B 209246 Inner Arm – rear 2 2
100
217500B
Parts box
10
217503B 0 1
101 217202 Oil hose 0 1
102 217146A Optional cable L=10144mm 0 2
103 201090 Shim 10 10
104 206154 Rear guard bar 2 2
105 206156 Tool tray 2 2
Parts For Hydraulic Cylinder
Item Part# Description
Qty.
Note
PV-10PX PV-10HPX
61-1 209069 O-Ring 2 2
61-2 209070 Bleeding Plug 2 2
61-3 209071 Support Ring 2 2
61-4 209072 Y-Ring 2 2
61-5 209073 O-Ring 2 2
61-6 209074 Piston 2 2
61-7 209075 O-Ring 4 4
61-8 217076 Piston rod 2 2
61-9 209077 Piston rod fi tting 2 2
61-10 209078 Dust ring 2 2
61-11 209079 Head cap 2 2
61-12 209080 O-Ring 2 2
61-13 209081A Bore weldment 2 2
