PREPARATION
Before beginning installation, inspect and check the box
contents and report any damage or missing items to Atlas.
INCLUDED parts
Installations may vary to some degree, but below are the basic tools to have on hand for a Rave II stair lift installation.
If you have any questions, concerns or comments, please contact our Technical Service Department at 866-378-6648.
REQUIRED TOOLS
• Cordless drill
• Allen wrenches (5/64",
(5/32", 3/16", 5/16")
• Phillips screwdriver (#3)
• Nut driver (3/8", 5/16")
• 6" - 10" driver extension
RAIL BOX CONTENT
• Chassis
• 2 wireless call/send hand controls
• Manual override tool (optional)
• Level
• Hack saw or chop saw
• SAE socket set
• SAE wrenches
• Tape measure
• Volt meter
• Rail accessories
(plastic bag) with:
− Top end plate
− Compression bolts
(2 sizes)
− Self-cutting screws
1/4"-20 x 1"
− Torx T30 driver bit
− Extra plastic racks
(2 or 3)
− Top limit cam
• Bottom rail pre-installed with:
− Bottom end plate
− Charge strip wire harness
• Bottom limit cam
• Joint pins (two-piece rail only)
• Plastic gear rack
• Top rail pre-installed with
charge strip wire harness
RAIL bracket box
• Rail brackets (2, 3, 4, or 6 per set)
• Wood screws #14 x 2" (4 per rail bracket)
CHAIR AND FOOTREST BOX
• Chair with retractable seatbelt
• Footrest complete with adjustable seat height frame
• Plastic vertical cover
• 5 nylon plugs
• Seat swivel post with fasteners
RAVE 2 INSTALLATION MANUAL PREPARATION
