What to do if my Atlas Scissor Lifts doesn't work?
If your Atlas Scissor Lifts isn't working, there are several potential causes: * The main switch might not be turned on: turn the switch on. * There might be no power: check the power and restore if necessary. * The electrical wires could be disconnected: reconnect them. * Fuses might be blown: replace them.
Why won't my Atlas TD6MR Scissor Lifts raise?
There are several reasons why your Atlas Scissor Lifts might not be raising: 1. The motor direction of rotation may not be correct: interchange the two phases on the main switch. 2. The oil in the hydraulic unit may not be sufficient: add some hydraulic oil. 3. There may be air in the hydraulic circuit: bleed the hydraulic system. 4. The UP button may be faulty: check the UP button and connection for proper operation. Replace it if needed. 5. The maximum pressure valve may be faulty: check and clean if dirty or replace if needed. 6. The lowering valve may be faulty: check and clean if dirty or replace if faulty. 7. The pump filter may be dirty: check and clean if needed. 8. The pump suction may be blown: check the seal and replace if needed.
How to fix an Atlas TD6MR Scissor Lifts that doesn't lift or lower smoothly?
If your Atlas Scissor Lifts isn't lifting or lowering smoothly, it could be due to: * Leakages or presence of air in the hydraulic circuit: bleed the hydraulic system. * The pump filter is dirty: check and clean if needed. * The pump suction is blown: check the seal and replace if needed.
What causes Atlas TD6MR platforms to not be leveled?
If the platforms of your Atlas Scissor Lifts are not leveled, it may be caused by oil leakages in the hydraulic circuit. Check the circuit for any leakage.
What to do if Atlas Scissor Lifts does not lower when the lowering lever is pressed?
If the Atlas Scissor Lifts does not lower when the lowering lever is pressed, the lowering valve may be faulty. Check and clean it if dirty, or replace it if faulty.
Instructions on how to properly use and maintain the manual for optimal reference.
Steps to follow in the event of a machine malfunction.
Precautions operators must take to ensure their safety while operating the lift.
Important warnings regarding modifications, safety devices, and usage.
Details the components and materials used for packing the lift for delivery.
Guidelines for safe lifting and handling of the packaged lift components.
Recommended conditions for storing packages, including temperature and humidity.
Procedures for checking the delivered package for damage and completeness.
Detailed explanation of the lift's components and their functions as shown in Figure 1.
Provides key dimensions and features of the lift as detailed in Figure 2.
Specifications and connection guidelines for the electric motor.
Technical details and specifications for the hydraulic pump.
Details the components and function of the hydraulic power unit.
Recommended type of oil and its properties for the hydraulic system.
Essential safety precautions and rules for operators and maintenance personnel.
Identifies risks associated with overloading and breaking during lifting.
General overview of risks personnel may face due to improper lift usage.
Hazards related to personnel being caught in the lowering trajectory of the lift.
Risk of bumping against projecting parts when the lift is at low heights.
Causes and consequences of a vehicle falling from the lift due to improper placement.
Hazards of slipping due to oil or dirt on the floor near the lift.
Dangers of electrocution from water or solvents near electrical components.
Importance of adequate lighting for safe operation around the lift.
Factors leading to component breakage during lift operation.
Dangers and consequences of unauthorized personnel operating or being near the lift.
Criteria for selecting a suitable and safe location for lift installation.
Requirements for the concrete surface to ensure stability and safety.
Instructions for connecting the hydraulic hoses and fittings correctly.
Procedure for safely connecting the electrical components to the hydraulic power unit.
Steps to follow to safely start and test the lift after installation.
Procedure for bleeding the hydraulic system to remove air.
Checks to perform on operating components after installation and before loading.
Procedures for verifying the lift's performance under load.
Identification and function of the lift's control buttons and levers.
Step-by-step instructions for safely lifting a vehicle using the lift.
Step-by-step instructions for safely lowering a vehicle.
Routine cleaning and lubrication tasks for the lift.
Scheduled maintenance tasks to be performed at specific intervals (3, 6, 12 months).
Illustration showing the lift and cylinder components with reference numbers.
Illustration of the control unit components with reference numbers.
Illustration of the hydraulic power unit components with reference numbers.
General| Weight | 3, 500 lb (1, 588 kg) |
|---|---|
| Drive Type | Electric |
| Power Source | Battery |
| Platform Capacity | 227 kg |
| Platform Size | 1.83 m x 0.76 m |
| Platform Length | 1.83 m |
| Power Unit | Electric |
| Platform Width | 0.76 m |
| Capacity | 227 kg |
| Turning Radius (Inside) | 0 in (0 m) |
