Atlona
2151 O’toole Ave Unit D
San Jose, CA 95131
Tel: 408-954-8782
Fax: 408-954-8792
toll free: 1-877-536-3976
www.AtlonA.com
AdoPtEr
Connection Diagram
Atlona HDMI Extender over single Cat5/6 with local video output (Transmitter Unit)
HDMI source
HDTV
Speaker
Audio cable
AT-HD50SS
AT-HD50RSL
AT-HD50RSL
HDMI cable
HDMI cable
HDMI cable
HDMI
cable
CAT5
cable
CAT5
cable
CAT5 cable
CAT5 cable
AT-HDRS
AT-HD15SRS
AT-HD15SRS
Audio cable
Audio cable
Speaker
Speaker
HDTV
HDTV HDTV
