CAUTION - the direct controlling function of solar heating from pellet burner cannot be
used for
DCxxSP(X)/(EP), CxxSP, ACxxSP
boilers and boilers with burner built into the
upper doors. This function also cannot be used when the pump is simultaneously controlled
in the boiler circuit from the burner regulation (TK sensor cannot be simultaneously in boiler
and accumulation tank)
o) S6 = 15….. Reserve function for the compressor control during the function for automatic
burner cleaning using compressed air. Power element designed for switching and powering the
compressor (e.g. contactor) must be connected between reserve output R and the compressor. This
function is connected with S6 (14), S41, S42, S43, S44, S45, S46, S47 parameter, which must be
checked and configured.
p) S6 = 16….. Reserve function for controlling el.fan during the function for automatic burner
cleaning using compressed air. This function is connected with S6 (14), S41, S42, S43, S44, S45,
S46, S47 parameter, which must be checked and configured.
Special function for turning on reserve output R according to the temperature of a concrete sensor:
a) e.g. function: TS>……. means that if the TS sensor temperature is higher then the set value in
S48 parameter – Temperature A, reserve output R will be activated
b) e.g. function: TS<……. means that if the TS sensor temperature is higher then the set value in
S48 parameter – Temperature A, reserve output R will be deactivated
c) e.g. function: TS, TV>……. means that if the TS and TV sensor temperature is higher at the
same time then the set value in S48 parameter – Temperature A and S50 – Temperature B, reserve
output R will be activated (Temperature A = first position (TS), Temperature B = second position
(Tv)).
d) e.g. function TS, TK<……. means that if the TS and TK sensor temperature is higher at the
same time then the set value in S48 parameter – Temperature A and S50 – Temperature B, reserve
output R will be deactivated (Temperature A = first position (TS), Temperature B = second position
(Tk)).
Individual functions:
(17) TS>
(18) TS<
(19) TV>
(20) TV<
(21) TK>
(22) TK<
(23) TSV>
(24) TSV<
(25) TS,TV>
(26) TS,TV<
(27) TS,TK>
(28) TS,TK<
(29) TS,TSV>
(30) TS,TSV<
(31) TV,TK>
(32) TV,TK<
(33) TV,TSV>
(34) TV,TSV<
(35) TK,TSV>
(36) TK,TSV<
