Operation and maintenance manual - EN
Special function for turning on reserve output R6 according to the temperature of a concrete sensor:
a) e.g. function: TS>… means that if the TS sensor temperature is higher then the set value in S52
parameter – Temperature C, reserve output R6 will be activated
b) e.g. function: TS<… means that if the TS sensor temperature is higher then the set value in
S52 parameter – Temperature C, reserve output R6 will be deactivated
c) e.g. function: TS, TV>… means that if the TS and TV sensor temperature is higher at the same
time then the set value in S52 parameter – Temperature C and S54 – Temperature D, reserve output
R6 will be activated (Temperature C = first position (TS), Temperature D = second position (Tv)).
d) e.g. function TS, TK<… means that if the TS and TK sensor temperature is higher at the same
time then the set value in S52 parameter – Temperature C and S54 – Temperature D, reserve output
R6 will be deactivated (Temperature C = first position (TS), Temperature D = second position
(Tk)).
Individual functions:
• Offset TV – this function is used to compensate the offset of the TV temperature sensor
(input) in the range of ± 9.9 °C.
• Offset TS – this function is used to compensate the offset of the TS temperature sensor
(input) in the range of ± 9.9 °C.
• Offset TK – this function is used to compensate the offset of the TK temperature sensor (input)
in the range of ± 9.9 °C
• Offset TSV – this function is used to compensate the offset of the TSV temperature sensor
(input) in the range of ± 9.9 °C
(17) TS>
(18) TS<
(19) TV>
(20) TV<
(21) TK>
(22) TK<
(23) TSV>
(24) TSV<
(25) TS,TV>
(26) TS,TV<
(27) TS,TK>
(28) TS,TK<
(29) TS,TSV>
(30) TS,TSV<
(31) TV,TK>
(32) TV,TK<
(33) TV,TSV>
(34) TV,TSV<
(35) TK,TSV>
(36) TK,TSV<
