Operation and maintenance manual - EN
INFORMATION menu
• Photocell – Displays the current value that the photocell sees.
• Temperature TS – displays the current TS temperature - (exhaust temperature (S15 = 1) or
lower temperature (S15 = 2))
• Temperature TV – displays the current TV temperature - (water temperature (S15 = 1) or upper
temperature (S15 = 2))
• Temperature TK – displays the current TK temperature - (boiler temperature (S15 = 1, S15 = 2,
S15 = 4, S6 = 12, S6 = 13, S14 = 12, S14 = 13), central tank temperature (S15 = 3, S6 = 14,
S14 = 14), central tank temperature as a second deactivation sensor for burner TS2 (S26 = 0))
• Temperature TSV – displays the current TSV temperature - (exhaust temperature (S15 = 1,
S15 = 2, S15 = 4, S34 = 1, S34 = 2), solar collector temperature (S15 = 3, S6 = 14, S14 = 14))
• Fan speed - displays the current speed of the fan
• Fan speed 2 – displays the current speed of fan 2 (not used)
• Conveyor - displays the current status of the conveyor
• Conveyor faults - displays information for the service engineer
• Spirals - displays the current status of the ignition spirals
• Spiral faults - displays information for the service engineer
• Reserve R - displays the current status of the reserve output R (parameter S6)
• Reserve R2 - displays the current status of the reserve output R2 (parameter S14)
• Reserve R5 - displays the current status of the reserve output R5 (parameter S67)
• Reserve R6 - displays the current status of the reserve output R6 (parameter S68)
Short explanation:
This always depends on whether the burner regulation function based on two temperatures on the
accumulation tank is on or off, and whether the automatic start function after wood burns out is activated.
The default settings are S15 = 1 and S34 = 0, which means that the function for controlling the
burner by two sensors is deactivated and the AUTOSTART function for DCxxSP(X)/(EP), CxxSP,
ACxxSP burns is also off. The burner is only controlled by thermoregulators on the boiler panel.
The customer may connect the exhaust temperature sensors TS and TSV and the water temperature
sensors TV and TK to the burner so that they only serve as information.
