EN
www.atmos.cz
90-EN
Operation and maintenance manual - EN
45. List of spare parts -
version for
PXxx Compact
POSI-
TION
PART DESCRIPTION
QUAN-
TITY
CODE
1 pc
1A Burner body - front part A25 1 H0217
1B Burner body - rear part A25 1 H0218
2 Burner cover - hood with a window for the display - AC07X 1 H0274
3 Top cover of the burner mouth 1 H0220
4 Holder of the electronic unit 1 H0221
5A Electronic unit of the burner - AC07X with a fixation plate + AC07X-C 1 H0310
5B AC07X-C additional module 1 H0337
6 Pellet supply pipe 1 H0223
7 Safety thermostat 95 °C 1 H0059
8 Safety thermostat cover 1 H0224
9 Holder - plate with openings for the ignition spirals - for pneumatic clening 1 H0277
10 Ignition spiral 500 W 2 H0229
11 Ignition spiral cover 1 H0226
12 Inner holder of the ignition spiral 1 H0227
13 Combustion chamber (pot) of the burner - for pneumatic clening 1 H0276
14 End switch - FR501 1 H0210
15 Burner connector - 6-pin - male - complete (power) 1 S0989
16 Burner connector - 6-pin - female - complete (sensors) 1 S0987
17 Socket for the external conveyor 1 H0211
18 Air flap of the fan 1 H0230
19 Fan with a speed sensor 1 H0058
20 Photocell - entire old Danfoss (Siemens) / new ATMOS FT01 1
H0231/H0330
21 Photocell holder 1 H0232
22 Electronic unit connector (1 - 12) - top 1 H0260
23 Electronic unit connector (1 - 16) - bottom 1 H0234
24 Electric harness of the burner, incl. bushings and connectors 1 H0216
25 Bushing for the cable to ignition spirals, safety thermostat, special applications 5 S1191
26 Gasket under the flange of the pellet supply pipe - Sibral paper 1 S0170
27 Screw for fixation of the hood and connection of the burner body 4.2 x 13 18 -
28 Fan attachment screw M4 x 8 4 -
29 Screw for attachment of the pellet supply pipe M5 x 10 3 -
30 Screw for attachment of the safety thermostat cover M4 x 6 1 -
31 Screw for attachment of the end switch and safety thermostat cover M4 x 30 3 -
32 Screw for attachment of the conveyor socket and fan flap 3.9 x 9.5 6 -
33 Nut M6 4 -
34 Screw M6 x 12 (stainless steel) 3 S0880
35 Display self-sticking label 1 H0236
36 End switch stop 1 H0237
37 Sealing for photocell Ø 8/15 1 S0155
38 Sealing under fan 72 x 79 1 S0156
39 Pneumatic cleaning channel with nut and washer 1 H0533
40 complete screw fitting (3/4”) with solenoid control and connecting cable 1 S1036
41 Fuse for ignitaton spiral - type F 3.15A/1500A/5x20 mm 2 H0238
42 Fuse for conveyor - type F 0.8A/1500A/5x20 mm 1 H0239
43 Fuse for fan - type F 1.0A/1500A/5x20 mm 1 H0251
