Atomos ZATO CONNECT - Page 41

HDMI
2ch, input dependent
Analogue Audio in
3.5mm Jack - 5v power
Analogue Audio Out
3.5mm Jack
Headphone out
3.5mm Jack
Resolution and Frame Rates
(Record, Monitor & Playback)
FHD 1920 x 1080 Progressive
up to 1080p60
Recording CODEC
H.264
up to 1080p60
Playback
Loop
Yes
H.264
up to 1080p60
UVC Out
up to 1080p60
Monitoring
SDR
Rec.709
Multi Input / Switching
Picture in Picture (PIP)
Picture-in-Picture from webcams / USB UVC devices, HDMI inputs, and recorded clips on
SD Card. Select position and size of PiP.
Graphic overlays
Upload custom 1920 x 1080 PNG graphics. Alpha transparency is supported. Can be used
simultaneously with PiP.
Supported media
SD
SD UHS-1 (up to 128GB size)
File System
exFAT, FAT32
On screen tools
2 x Zoom
Tap to zoom
Social Frame guides
16:9, 1.91, 4:3, 1:1, 4:5, 9:16
Grid markers
9 Grid
