Audi A4 Avant 2002 - SDARS System Layouts

91-36
Radio system SDARS with BOSE sound
system (Sedan), layout
1 - Rear window antennas
2 - Antenna Selection Control Module -J515-
Under rear headliner trim
3 - Radio
4 -
BOSE power amplifier
In right rear luggage compartment behind
side trim
5 - Front Midrange Speakers
In upper front door trim
6 - Front Bass Speakers
In lower front door trim
