Radio system SDARS with BOSE sound

system (Avant), layout

1 -

Left Antenna Module

In left rear luggage compartment behind

trim

2 -

Left rear window antenna

3 -

Rear window antenna

4 -

Right rear window antenna

5 -

Radio

6 -

BOSE power amplifier

In right rear luggage compartment behind

trim

7 -

Front Midrange Speakers

In upper front door trim

8 -

Front Bass Speakers

In lower front door trim
