91-40
Communication system with SDARS, layout
1 - Satellite Radio
In left rear luggage compartment
2 - Satellite Tuner Antenna
on roof
3 - Antenna splitter (GPS)
Only Avant
In left rear luggage compartment behind
trim
4 - Antenna for Navigation (GPS)
Only sedan
Behind roof end trim
5 - Control module for navigation with CD
mechansim
In left rear luggage compartment behind
trim
Audi A4 Sedan 2002-2004, Audi A4 Avant 2002-2004, Audi A4 Cabriolet 2003-2004 - Communication
