91-62
Bass Loudspeaker -R100- (Avant),
removing and installing
Removing
- Open cover in side trim on right rear side of
luggage compartment.
Installing
- Disconnect electrical connections -1- and -2-.
- Unscrew bolts -arrows-.
- Remove bass loudspeaker -3- together with amplifier -4-.
- Install in reverse order of removal.
- Tighten bolts on loudspeaker to 2 Nm.
