LEAKS (FALSE AIR) .
P1292 17700
F265 - Map Controlled Engine Cooling
T
hermostat
Cooling system components, overview
P1293 17701
P1294 17702
P1296 17704
Malfunction in cooling system

Check Engine Coolant Temperature
(ECT) Sensor -G62-. See E
NGINE
COOLANT TEMPERATURE
(ECT) SENSOR -G62-,
CHECKING .
 C
heck coolant regulator:
P2101 18533
Throttle Actuator Control Motor Circuit
R
ange/Performance
 C
heck Throttle Valve Control
Module -J338-. See THROTTLE
VALVE CONTROL MODULE -
J338-, CHECKING .
P2122 18554
Throttle/Pedal Position Sensor/Switch
"
D" Circuit Low Input
 C
heck Throttle Position (TP)
sensor. See THROTTLE
POSITION (TP) SENSOR,
CHECKING .
P2123 18555
Throttle/Pedal Position Sensor/Switch
"
D" Circuit High Input
P2127 18559
Throttle/Pedal Position Sensor/Switch
"
E" Circuit Low Input
P2128 18560
Throttle/Pedal Position Sensor/Switch
"
E" Circuit High Input
P2138 18570
Throttle/Pedal Position Sensor/Switch
"
D" / "E" Voltage Correlation
P2400 18832
Evaporative Emission System Leak
D
etection Pump Control Circuit/Open
 C
heck Leak detection pump (LDP)
-V144-. See LEAK DETECTION
PUMP (LDP) -V144-,
CHECKING .
 E
VAP canister system, check for
proper seal. See EVAP
CANISTER SYSTEM,
CHECKING FOR PROPER
SEAL .
P2401 18833
Evaporative Emission System Leak
D
etection Pump Control Circuit Low
P2402 18834
Evaporative Emission System Leak
D
etection Pump Control Circuit High
P2403 18835
Evaporative Emission System Leak
D
etection Pump Sense Circuit/Open
P2404 18836
Evaporative Emission System Leak
D
etection Pump Sense Circuit
Range/Performance
2005 Audi A4 Quattro
DTC INDEX DTC Index - 1.8L (AMB Engine)
11:32:48 PM Page 10
