Fig. 188: Removing Engine Cover
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove engine cover - arrows -.
Remove top section of toothed belt guard --> Toothed drive belt, removing, installing and tensioning.
Fig. 189: Locating Connector At Camshaft Position Sensor G40
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Disconnect connector from Camshaft Position (CMP) sensor G40 - arrow -.
Remove housing for CMP sensor G40.
Remove washer and CMP sensor rotor rin
.
