Removing
With engine in vehicle.
Move lock carrier to service position --> Lock carrier in service position, overview.
Fig. 83: Removing Engine Cover By Lifting Up
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove engine cover by lifting up - arrows -.
Remove ribbed belt --> Ribbed belt, removing and installing.
Fig. 84: Removing/Installing Ribbed Belt Tensioner
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove ribbed belt tensioner - arrows -.
