Audica microplus - Page 5

GAIN
GAIN
CHANNEL 3 CHANNEL 4
IN
OUT
IN
OUT
GAIN
CHANNEL 1 CHANNEL 2
IN
OUT
GAIN
IN
OUT
NORMAL
BRIDGED
CHANNEL 1 & 2 BRIDGED CHANNEL 3 & 4 BRIDGED
220-240v~
100-120v~
CH3&4
CH1
CH3
CH4CH2
CH1&2
SERIAL No.
~50/60Hz
350W
[2 x MICROdot series / 16 ] +
[2 x MICROdot series / 16 ]
Wired in parallel =
4 MICROdot @ 8 driven by 40W.
MICROdot per MICROplus:
With 4 channels this will give a total of
16 x MICROdot per MICROplus
Ohm
Ohm
Ohm
[1 x MICROline / 8 ] +
[1 x MICROline / 8 ]
Wired in parallel =
2 x MICROline @ 4 driven by 80W.
MICROline per MICROplus:
With 4 channels this will give a total of
8 x MICROline per MICROplus
Ohm
Ohm
Ohm
2 MICROline per channel:
4 MICROdot per channel:
If less speakers are required, the 8 capability of the MICROplus may be the best solution. Ohm
GAIN
GAIN
CHANNEL 3 CHANNEL 4
IN
OUT
IN
OUT
GAIN
CHANNEL 1 CHANNEL 2
IN
OUT
GAIN
IN
OUT
NORMAL
BRIDGED
CHANNEL 1 & 2 BRIDGED CHANNEL 3 & 4 BRIDGED
220-240v~
100-120v~
CH3&4
CH1
CH3
CH4CH2
CH1&2
SERIAL No.
~50/60Hz
350W
