• EXIT: selecting this option (pushing the 5: OK button on the remote) exits you from the menu set up, the same result is
achieved pushing the AMP SETUP button on the remote when you are in any section of the menu.
o EXIT: selezionando questa voce del menu (premendo il tasto 5: OK del telecomando ) si esce dal menu setup, lo stesso
effetto si ha anche con la pressione del tasto AMP SETUP in qualunque schermata.
NOTES
NOTE
• All the settings, which are re-loaded every time the unit is turned on, are memorized in EEPROM so even if the power
supply is switched off the settings are not lost.
o tutti i settaggi vengono memorizzati in EEPROM così da poter essere ricaricati all’accensione, in modo che anche
togliendo l’alimentazione all’apparecchio, queste informazioni non vengano perse.
• Access to the Setup menu is not enabled in CD Mode with REPEAT TRACK and REPEATA>B.
o l’accesso al menu SETUP in modalità CD non è abilitato nelle modalità di riproduzione REPEAT TRACK e REPEAT A>B.
Technical Data
Power consumption: 300VA
125 x 210 x 400 mm
Dimensions (Nota 1)
4,9 x 8,3 x 15,7 "
9,3 kg
Weight
20,5 Lbs
Line Gain 12dB
Power Amp Gain 26dB
Line Input impedance 40KOhm
10W @ 0.010% THD + N
40W @ 0.016% THD + N
Power on 8Ohm load, Input Line2 (Note 6)
50W @ 0.017% THD + N
Frequency responce (Note 2) 110KHz
Vout: 50Vpp
Responce to a Square Signal (Note 4)
Rise time: 3.3uS
98 dB (A weighted)
Signal Noise Ratio (Note 3)
95dB (No filter)
Noise level (Nota 5) -100dB
DAC: Burr Brown Enh.Multi. Sigma Delta PCM1781
Receiver: Burr Brown DIR9001
DAC Section
Full Scale Output = 3.9Vpp
AM: Signal Noise ratio =49dB min.
FM: Signal Noise Ratio = 72dB min.
Electr.Tuning: SANYO LA1837
Tuner Section
AM/FM PLL Freq. Synth: SANYO LC7213
Dynamic Range (Nota 8) 97dB
ENOB (Note 7) 15.65Bit
Inputs 2 Line Unbalanced Input + 1 Front Line Input
Outputs 1 Stereo MonoOut + Front Headphone Out
Notes:
Nota 1 - Height x Width x Depth (H x W x D)
Nota 2 - Attenuation 0dB, -3dB Band
Nota 3 - Attenuation: 0dB A weighted referred to 8 Ohm load nominal power
Nota 4 - 1KHz input signal, two piloted channels
Nota 5 - Band limits 0Hz-40KHz
Nota 6 - Band limits 0Hz-22KHz
Note 7 - ENOB = Effective number of Bits
Nota 8 - Measurement conditions: Source Selected CD Player, Volume = 0dB attenuation, Signal = - 60dB, 1KHz pure sine wave
track; Dynamic Range = measured THD + N value with a 20Hz-22KHz filter (no other filter!) in the described conditions
+60dB.
