Audio Technica 3000 Series User Manual

56
Setting the audio mode (AUDIO MODE)
The modes that can be selected vary depending on the RF mode setting. The modes that can be selected are as follows.
When RF mode is set to “Stereo”
Item
Description
Stereo
The stereo input signal is output to L/R in stereo.
Mix
Mix the input signal in stereo and output the same audio in L and R.
Mono Bal
Mix the input signal in stereo and output balanced audio in monaural.
When RF mode is set to “Mono” / “3000Link”
Item
Description
Dual Mono
The signal input in monaural is output to L/R in monaural.
Mono Bal
The input signal in monaural is output balanced audio in monaural.
1
From the menu screen, press the UP/DOWN button to select “AUDIO” and press the SET button.
2
Select “AUDIO MODE” and press the SET button.
3
Select “Stereo” / “Dual Mono
”
/ “Mono Bal” / “Mix”
and press
the SET button.
The setting is complete.
Adjusting L/R sound panning or mix balance. (BALANCE)
1
From the menu screen, press the UP/DOWN button to select “AUDIO” and press the SET button.
2
Select “BALANCE” and press the SET button.
3
Press the UP/DOWN button to adjust, then press the SET button.
• When “AUDIO MODE” is set to “Stereo” or “Dual Mono”, this function adjusts the L/R sound panning.
• When “AUDIO MODE” is set to “MIX” or “Mono Bal”, the L/R mix balance is adjusted.
The setting is complete.
