Audio Technica ATH-ANC700BT User Manual

9
Using the product
You can fold the housing so that it lies flat. After folding it flat, you can also fold the housing inside the headband.
• The swivel mechanism cannot rotate more than 90 degrees. Do not apply excessive force to this mechanism.
Using the joint as a fulcrum, the housing can be folded into the headband.
• When folding the product, detach the included cable.
• Be careful not to pinch your fingers, etc. in the joint.
• Be sure to return the housing to its original position before using the product.
Swivel mechanism
Folding compactly
Folded down and flat
Flat, with housing
folded inward
Joint
“R” (RIGHT)
side
“L” (LEFT)
side
Joint
Fold
Unfold

Audio Technica ATH-ANC700BT Specifications

General

Headset type	Binaural
Product type	Headphones
Product color	Black
Wearing style	Head-band
Operating keys	Play/Pause
Volume control	Touch
Recommended usage	Calls/Music
Wireless range	10 m
3.5 mm connector	Yes
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Connectivity technology	Wireless
Microphone type	Built-in
Microphone frequency	50 - 4000 Hz
Microphone sensitivity	44 dB
Microphone direction type	Omnidirectional
Battery type	Built-in battery
Battery recharge time	5 h
Input voltage (earpieces)	3.7 V
Continuous audio playback time	25 h
Quantity	1

Weight and Dimensions

Weight	250 g
