Audio Technica ATH-ANC700BT User Manual

5
Part names and functions
Accessories
• Cable (1.2 m (3.9’) / 3.5mm
(1/8“) gold-plated stereo
mini-plug)*
• USB charging cable
(30cm (12“))
• Pouch
* The diameter is 2.5 mm (3/32“) on the straight plug side and 3.5 mm (1/8“) on the L-shaped plug side.
L/R (left/right)
indicator
Slider
Arm
Joint
Housing
Headband
Earpad
Touch panel (L)
Used to play/pause music and video,
answer/end phone calls, adjust the
volume, and turn the noise-cancelling
function on/off.
Connector jack
Used to connect the included
cable and use the playthrough
function.
Battery jack
Used to connect the included
USB charging cable to charge
the product.
Multi-indicator lamp
Displays the operating status
and battery level of the product.
Power switch
Turns the power on
and off.
A built-in microphone (for
talking) is integrated into
the L (left) housing.
Noise-cancelling
indicator lamp
Displays the operating status of
the noise-cancelling function.

Audio Technica ATH-ANC700BT Specifications

General

Headset type	Binaural
Product type	Headphones
Product color	Black
Wearing style	Head-band
Operating keys	Play/Pause
Volume control	Touch
Recommended usage	Calls/Music
Wireless range	10 m
3.5 mm connector	Yes
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Connectivity technology	Wireless
Microphone type	Built-in
Microphone frequency	50 - 4000 Hz
Microphone sensitivity	44 dB
Microphone direction type	Omnidirectional
Battery type	Built-in battery
Battery recharge time	5 h
Input voltage (earpieces)	3.7 V
Continuous audio playback time	25 h
Quantity	1

Weight and Dimensions

Weight	250 g
