Audio Technica M2 User Manual

13
EN
M-Band
GroupA GroupB GroupC GroupD GroupE GroupF GroupG GroupH GroupI GroupJ
CH-1 615.125 614.000 614.500 615.875 616.750 614.750 614.875 614.125 614.250 616.625
CH-2 619.625 619.500 619.500 619.625 617.750 618.750 615.625 621.125 617.625 617.125
CH-3 621.375 622.000 626.125 620.375 622.625 621.000 620.500 622.375 622.250 618.875
CH-4 624.375 623.125 632.375 622.375 624.500 631.250 624.125 628.625 623.875 623.875
CH-5 630.875 628.250 634.375 630.625 629.625 633.750 626.875 629.625 631.125 626.875
CH-6 632.375 629.125 641.500 633.625 632.625 635.750 629.250 636.375 632.500 633.375
CH-7 639.875 639.500 642.000 640.375 642.250 642.500 637.125 640.625 636.625 640.875
CH-8 642.625 642.250 644.500 642.125 643.000 643.500 641.500 642.375 642.500 641.875
CH-9 644.875 644.000 645.500 643.625 646.625 645.250 643.125 645.625 643.625 645.375
CH-10 646.875 647.000 646.250 646.125 646.875 646.750 644.500 646.375 644.375 646.625
Used U.S.
TV - 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40, 38, 39, 40,
Channels 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43 41, 42, 43
Used
European 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41, 39, 40, 41,
TV-Channels 42, 43 42, 43 42, 43 42, 43 42, 43 42, 43 42, 43 42, 43 42, 43 42, 43
M2 Frequency Plans
L-Band
GroupA GroupB GroupC GroupD GroupE GroupF GroupG GroupH GroupI GroupJ
CH-1 576.125 575.000 575.500 576.875 577.750 575.750 575.875 575.125 575.250 577.625
CH-2 580.625 580.500 580.500 580.625 578.750 579.750 576.625 582.125 578.625 578.125
CH-3 582.375 583.000 587.125 581.375 583.625 582.000 581.500 583.375 583.250 579.875
CH-4 585.375 584.125 593.375 583.375 585.500 592.250 585.125 589.625 584.875 584.875
CH-5 591.875 589.250 595.375 591.625 590.625 594.750 587.875 590.625 592.125 587.875
CH-6 593.375 590.125 602.500 594.625 593.625 596.750 590.250 597.375 593.500 594.375
CH-7 600.875 600.500 603.000 601.375 603.250 603.500 598.125 601.625 597.625 601.875
CH-8 603.625 603.250 605.500 603.125 604.000 604.500 602.500 603.375 603.500 602.875
CH-9 605.875 605.000 606.500 604.625 607.625 606.250 604.125 606.625 604.625 606.375
CH-10 607.875 608.000 607.250 607.125 607.875 607.750 605.500 607.375 605.375 607.625
Used U.S.
TV - 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33, 31, 32, 33,
Channels 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36 34, 35, 36
Used
European 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36, 34, 35, 36,
TV-Channels 37, 38 37, 38 37, 38 37, 38 37, 38 37, 38 37, 38 37, 38 37, 38 37, 38
E-Band
GroupA GroupB GroupC GroupD GroupE GroupF GroupG GroupH GroupI GroupJ
CH-1 790.850 790.300 790.100 790.750 790.100 790.300 790.100 800.100 806.125 790.000
CH-2 792.525 790.700 790.600 791.250 790.500 791.000 790.500 800.350 806.375 790.250
CH-3 793.925 791.950 792.050 792.500 792.025 792.975 792.750 801.100 807.125 791.000
CH-4 797.750 796.150 794.425 794.500 794.225 796.000 796.425 803.350 810.650 793.250
CH-5 798.850 798.700 797.500 801.250 797.300 802.775 800.750 811.900 812.150 795.250
CH-6 809.175 806.300 808.050 807.750 802.975 805.100 805.400 813.900 813.400 796.750
CH-7 811.100 809.775 812.950 812.250 813.300 813.900 810.675 815.400 813.900 801.500
CH-8 813.300 812.625 813.900 815.250 818.225 818.025 812.425 818.150 792.000 804.250
CH-9 813.800 813.600 797.900 819.250 820.900 821.500 813.900 819.400 794.325 805.500
CH-10 810.325 792.950 809.325 819.500 821.700 821.900 791.750 819.900 797.325 806.000
Notes: German German German French French French German 800.100 channel 63 channel 61+
user user user series 1 series 2 series 3 user 819.900 focus 62 only
group d) group cc) group b) group a)
German German German German
musicians rental private public
companies broadcasters broadcasters
F-Band
GroupA GroupB GroupC GroupD GroupE GroupF GroupG GroupH GroupI GroupJ
CH-1 854.900 863.100 838.850 838.300 838.100 838.100 832.000 832.500 832.000 863.125
CH-2 855.275 863.500 840.525 838.700 838.600 838.500 832.250 832.750 832.250 863.375
CH-3 856.575 864.900 841.925 839.950 840.050 840.750 833.000 833.500 833.000 864.900
CH-4 857.625 854.125 845.750 844.150 842.425 844.425 835.250 836.500 835.250 832.000
CH-5 860.900 854.775 846.850 846.700 845.500 848.750 837.250 840.750 837.250 832.500
CH-6 861.550 856.825 857.175 854.300 856.050 853.400 838.750 843.250 854.000 833.250
CH-7 864.550 857.975 859.100 857.775 860.950 858.675 844.250 856.250 857.500 836.050
CH-8 838.025 838.375 861.300 860.625 861.900 860.425 851.500 858.500 860.250 839.100
CH-9 839.950 839.275 861.800 861.600 845.900 861.900 857.500 859.750 861.500 853.000
CH-10 838.275 842.725 858.325 840.950 857.325 839.750 860.250 861.250 862.000 858.575
UK shared deregulated+ German German German German Fullrange Fullrange2 66 + 69 deregulated
frequencies 69 (Spain) user user user user first first
+ch 67 use UK indoor group d) group cc) group b) group a)
for Dutch Dutch ch 67
German German German German
musicians retail private public
companies broadcasters broadcasters
P52001_M2-System_OM 2/13/08 4:16 PM Page 13
