Installation & Maintenance Manual 11. Installing and Configuring the SBA
Version 6.8 119 Microsoft Lync Server
11.14.2 Running the Lync Call Test
The procedure for running the Lync test call is described below.
To run the Lync test call:
1. Select the Setup tab, and then select the Lync Test Call option; the Lync Test Call
screen is displayed:
Figure 11-60: Lync Test Call Screen
2. In the ‘Dial Check Phone Number’ field, enter the PSTN phone number to dial.
3. Click Apply to start the test call.
If the test is successful, the phone of the PSTN user rings and when the handset is lifted,
the DTMF tones are heard. If the phone does not ring, an error message is displayed on
the screen. The screen displays logged details of the call:
Figure 11-61: Lync Test Call – Logged Call Test Result
