Installation & Maintenance Manual 11. Installing and Configuring the SBA

Version 6.8 123 Microsoft Lync Server

11.15.2 Apply Default Security Template

This procedure describes how to apply the default security template.

 To apply the default security template:

1. Select the Setup tab, and then click the Apply Security option; the following screen is

displayed:

Figure 11-65: Apply Security Policy- Use Default Template
