CHAPTER72 Configuration Parameters Reference
Mediant 800 Gateway & E-SBC | User's Manual
Parameter Description
Note: To join a conference, the INVITE URI must
include the Conference ID string preceded by the
number of the participants in the conference and
terminated by a unique number. For example:
INVITE sip:4conf1234@10.1.10.10
INVITE messages with the same URI join the same
conference.
Automatic Gain Control (AGC) Parameters
'Enable AGC'
configure voip > media
ipmedia > agc-enable
[EnableAGC]
Global parameter enabling the AGC feature.
You can also configure the feature per specific calls,
using Tel Profiles (TelProfile_EnableAGC). For a
detailed description of the parameter and for
configuring the feature in the Tel Profiles table, see
Configuring Tel Profiles.
Note: If the feature is configured for a specific Tel
Profile, the settings of the global parameter is ignored
for calls associated with the Tel Profile.
For a description of AGC, see Automatic Gain Control
(AGC).
'AGC Slope'
configure voip > media
ipmedia > agc-gain-slope
[AGCGainSlope]
Determines the AGC convergence rate:
■ [0] 0 = 0.25 dB/sec
■ [1] 1 = 0.50 dB/sec
■ [2] 2 = 0.75 dB/sec
■ [3] 3 = 1.00 dB/sec (default)
■ [4] 4 = 1.25 dB/sec
■ [5] 5 = 1.50 dB/sec
■ [6] 6 = 1.75 dB/sec
■ [7] 7 = 2.00 dB/sec
■ [8] 8 = 2.50 dB/sec
■ [9] 9 = 3.00 dB/sec
■ [10] 10 = 3.50 dB/sec
■ [11] 11 = 4.00 dB/sec
■ [12] 12 = 4.50 dB/sec
■ [13] 13 = 5.00 dB/sec
■ [14] 14 = 5.50 dB/sec
■ [15] 15 = 6.00 dB/sec
■ [16] 16 = 7.00 dB/sec
■ [17] 17 = 8.00 dB/sec
■ [18] 18 = 9.00 dB/sec
■ [19] 19 = 10.00 dB/sec
■ [20] 20 = 11.00 dB/sec
■ [21] 21 = 12.00 dB/sec
■ [22] 22 = 13.00 dB/sec
- 1425 -
