ASSEMBLY PARTS LIST
M-DAC
M-DAC-Product Parts List-P1/1
18
No. P/N PART NAME DESCRIPTION QTY UNIT
1 340-1018420000R knob black painted 1 PCS
2 243-1009410000R plastic pad φ6*φ9*6.5MM， 1PCS
3 206-1018420002R lens 85.3*39.3*1.5mm, transparent 1 PCS
4 300-1018420001-1R front panel silkscreened, light grey(BLACK) 1 PCS
5 263-0074020052R EVA 74*2*0.5 (thickness)mm，EVA，black 3 PCS
6 262-0500005010R dustproof pad 5*50*0.25dustproof 6 PCS
7 226-0330050331R feet pad 33*5*3 (thickness) mm，PORON，black 2 PCS
8 308-1018420000R metal block painted 1 PCS
9 588-3000066037R screw M3*6 19 PCS
10 231-2000000052R feet RF11-5I 、SILICON、black 4 PCS
11 309-1018420001-1R main chassis black anodized 1 PCS
12 534-3002100906R screw M3*10 10 PCS
13 300-1018420002-1R back panel silkscreened, light grey(BLACK) 1 PCS
14 524-2023061001R screw M2*6.5 1 PCS
15 524-2923091016R screw M3*9.5 8 PCS
16 215-1027420001R button cap silver painted,ABS757# 1 PCS
17 205-1018420000R button bracket 30*40*4mm,ABS 1 PCS
18 231-3007005102R rubber washer Φ5*Φ7*1mm 4 PCS
19 340-1018420001R function button black painted 4 PCS
20 500-3050240300AR nut M3 NI 2 PCS
21 215-1027420000R power button silver painted,ABS757# 1 PCS
22 262-0200013011R washer φ20*φ13*2.6MM，black 2 PCS
To Next Page
