ELECTRONIC PARTS LIST
M-DAC
41 2 274-2001900168R Washer FR4 1.6 ，17.5*18MM 1 PCS
42 2 277-0130000000R Washer TW-136 10 PCS
43 2 323-1117000331R Crystal Base Insulator 4.4*10.8*1.0 HC-49 QW- 1 1 PCS X1a
44 2 324-0180130100R Mica TO-220 18*13MM 10 PCS
45 2 538-3001080301R Screw M3x8 10 PCS
46 2 604-1018420000R Heatsink H40mm x W23mm x D15.5mm 10 PCS
20
M-DAC Electronic Bom--P1/5
No. LEVEL P/N PART NAME DESCRIPTION QTY UNIT LOCATION
1 1 022-1000023405R Power adaptor
INPUT=AC120V
OUTPUT=AC13.8V*2,0.5A,USA Mains Cable
1PCS
2 1 032-1018420000R Remote AUDIOLAB MDAC ，black 180*3 1 PCS
3 1 036-1307015000R Battery 1.5V SIZE AAA 2 PCS
4 1 055-4324260066R FFC Cable
24pin PH=1MM L=280MM C type 0.1mm
black
1PCS
5 1 088-1018420000R Main board PCBA Main board PCBA 1 PCS
6 2 006-1014051123-3R Electrolytic Capacitor
100uF/10V 20% D5*11MM PH=2.5MM Lelon
RXY series 105℃
11 PCS
C48.C49.C56.C57.C68.C69.C91.C92.C9
6.C99.C101
7 2 006-1014060833R Electrolytic Capacitor
100uF16V 6.3*8 20% 105℃ Lelon OCRZ
series
4 PCS C120.C121.C130.C131
8 2 006-1014061143-3R Electrolytic Capacitor
100uF/25V 20% D6.3*11MM PH=5MM Lelon
RXY series
5 PCS C75.C77.C79.C81.C83
9 2 006-1024080803R Electrolytic Capacitor 1000uF 4V8*8 20% 105℃ Lelon OCRZ series 25 PCS
C25.C26.C27.C28.C29.C30.C31.C32.C3
3.C34.C35.C36.C37.C38.C39.C40.C41.C
42.C63.C64.C65.C66.C67.C87.C88
10 2 006-1024081213R Electrolytic Capacitor
1000uF,6.3V,105DegC,8mmDia,12mmH,3.5m
mPitch,Lelon,20%
4 PCS C43.C45.C51.C53
11 2 006-2214061133-1R Electrolytic Capacitor
220uF/16V 20% D6.3*11MM PH=5MM Lelon
RXY series
4 PCS C76.C78.C80.C82
12 2 006-3314061123-1R Electrolytic Capacitor
330uF/10V 20% D6.3*11MM PH=5MM Lelon
RXY series
11 PCS
C58.C59.C61.C70.C71.C74.C84.C94.C9
7.C100.C103.
13 2 006-3914081223R Electrolytic Capacitor
390uF 10V 8mm Dia 12mm H 3.5mm Pitch
Lelon OCRZ series
4 PCS C124.C125.C134.C135.
14 2 006-4714061113-1R Electrolytic Capacitor
470uF/6.3V 20% D6.3*11MM PH=5MM Lelon
RXY series
15 PCS
C44.C46.C47.C50.C52.C54.C55.C60.C6
2.C72.C73.C85.C86.C89.C90
15 2 006-4724123533R Electrolytic Capacitor 4700u/16V 20% Lelon RZD 12.5*35mm 105℃ 24 PCS
C104.C105.C106.C107.C108.C109.C110
.C111.C112.C113.C114.C115.C116.C11
7.C118.C119.C126.C127.C128.C129.
16 2 006-5604051130R Electrolytic Capacitor
56uF/16V 20% D5*11mm 105℃ Lelon RXY
series
4 PCS C93, C95, C98, C102
17 2 016-1017000001R Capacitor
100pF/400V 5% PH=2.5MM 2.5*7*4.6MM
WIMA FKP02
4 PCS C9.C12.C19..C24
18 2 016-1021132201QR Capacitor FKP2 1000PF/100V 2.5% WIMA PCM5 8 PCS C3.C4.C5.C6.C15.C16.C20.C21
19 2 016-1031130001R Capacitor
10NF/100V 2.5% EVOX RIFA
(PFR5103J100J13L4)
8 PCS C1.C2.C7.C10.C13.C14.C17.C22
20 2 016-3317000001R Capacitor
330pF/400V 5% PH=2.5MM 2.5*7*4.6MM
WIMA FKP02
4 PCS C8.C11.C18.C23
21 2 017-1240000000R IC L7812CV TO-220 ST 2 PCS U58.U59
22 2 017-1377000000R IC MC7805CTG TO-220 ON 5 PCS U53.U54.U55.U56.U57
23 2 017-1378000000R IC LM337T（1.5A） TO-220 NS 2 PCS U64.U67
24 2 017-1380000000R IC LM317T(1.5A) TO-220
（
ST
）
3 PCS U63.U65.U66
25 2 017-7510000000R IC L7808 +8v TO220 ST 1 PCS U60
26 2 018-9807912111R IC L7912CV TO-220 ST 2 PCS U61.U62
27 2 020-1022120017R Potentiometer
1K 100ppm/℃
±10% WI3362NOXOX-PA2-
B1K
4 PCS RV1.RV2.RV3.RV4
28 2 024-1120101011R Relay HJR1-2C-12VDC 3 PCS RLY2.RLY5.RLY7
29 2 044-4850000000R Dual 3.5mm Stereo Jack Dual Vertical PCB Mount 3.5mm 1 PCS CN7
30 2 044-4860000000R RCA + Toslink Combo
Combined 16Mbps Optical receiver & Gold
plated RCA JACK JSR1583
2 PCS CN3.CN4
31 2 044-5500000000R RCA Jack Black PCB Mount 180Deg Black AEC Connectors 1 PCS CN8
32 2 044-5510000000R RCA Jack Black PCB Mount 180Deg RED AEC Connectors 1 PCS CN12
33 2 044-5520000000R UBSRA-004 USB, Thur Hole, Gold Plated 1 PCS CN6
34 2 044-5550000000R XLR Jack PCB Mount 90Deg XLR Jack LX-1601H-3 2 PCS CN11.CN9
35 2 044-5690000000R RCA + Toslink Combo
Combined 16Mbps Optical & Gold plated
RCA JACK JSR1583
1 PCS CN5
36 2 049-1309223000R 6.35mm Stereo Jack Vertical PCB Mount 6.35mm Stereo Jack 1 PCS CN13
37 2 050-0400000000R Transistor Clip 10*6MM TR-1 5 PCS
U53 Support.U54 Support.U55
Support.U56Support.U57 Support.
38 2 056-4110000000R Connector 10PIN 2.54 Box Header 1 PCS CN1
39 2 059-8400002331R Crystal
Crystal 84MHz AT5thOT,+/-30PPM HC-49/U
3P(Centre Ground PIN)
1PCS X1
40 2 271-0180000000R Plastic Post Kangyang PDC-5.5D H=5.5 MM 1 PCS
To Next Page
