128-8971a
3 of 32
3
16 Pin Main Wiring Harness #1124049
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Purple Door Trigger Input (+)
Black/White Horn Output (-) 300mA
Yellow/Black To Factory Alarm Or Keyless Ignition
Light Blue Ground Output While Running (-) 300mA
Dark Green Instant Trigger Input Hood & Trunk
Dark Blue/Black External Remote Start Trigger Input
White/Black Siren Output (+)
Green/Orange Tachometer Input
White/Red Parking Light Input
White Parking Light Output
Green/Yellow Diesel Wait To Start Input
Brown Door Trigger Input (-)
Black Chassis Ground
Brown/Black Brake Shutdown Input (+)
Orange Ground While Armed Output (-)
Grey Shutdown Input (-)
2 Pin Door Lock Output Harness #1122242
1
2
Red (-) Lock / (+) Unlock
Green (+) Lock / (-) Unlock
4 Pin Alternate Output Harness #1122585
1
3
Black/Blue Factory Disarm / Pulse Beffore Start (-)
Black/Green Factory Arm / Pulse After Start (-)
Black/Red Pulse After Shutdown (-)
2
4
Black/Yellow Pulse During Crank (-)
To Next Page
