2. Whenever the system is armed, the Dash Mount PRLED, or the optional
on windsheild mount receiver's LED indicator will slowly flash. This serves
as a visual deterrent to the potential thief. The LED is a very low current
bulb,and will not cause the vehicle’s battery to drain, even when the vehicle
is left unattended for extended periods.
3. Whenever the system is triggered, the vehicle’s parking lights will flash for
the 30 second alarm cycle, attracting added visual attention to the vehicle.
4. Whenever the system is armed, the vehicle’s starter will be disabled. The
vehicle will not start.
DISARMING THE SYSTEM: (Only If Alarm Features Are Selected On)
1. As you approach the vehicle, press and release the unlock button on the
keychain transmitter.
2. The siren and or horn will beep two times, the parking lamps will flash two
times, and the PRLED, or optional on glass receiver's LED will turn off,
indicating that the system is DISARMED.
NOTE: If your system has been programmed for "passive arming", then
it will begin to re-arm immediately after disarming. This is
indicated by a rapid flashing of the dash mounted PRLED, ot
the optional on glass receiver's LED. Opening one of the
vehicle’s doors will suspend the passive arming process until
all doors have been closed, or until the ignition key has been
turned on.
INTRUSION WARNING SIGNALS: (Only If Alarm Features Are Selected On)
The system will inform you if an intrusion attempt has occurred while you were
away from the vehicle. If an intrusion attempt has occurred, the siren and or
horn will beep four times when the system is disarmed. The vehicle’s parking
lights will also flash three times to indicate an intrusion has occurred.
Enter the vehicle and observe the dash mounted LED or the optional on glass
receiver's LED for further information.
1. If the LED is flashing one time, pause, one time, pause, etc., then an
intrusion attempt was made to a sensor connected to zone 1.
