1
2
3
4
6
8
7
9
5
OPEN
NAV
CONTROLS AND INDICATORS
1. Disc Slot
2. EJECT
Press to eject a disc.
3. Power On/Off (
)/SRC
Press to turn the unit ON. Press and hold to turn the unit OFF. Once the unit is ON,
momentarily pressing the SRC button will display the Main Source Menu.
4. NAV
When a NAV104 is connected, this button toggles back and forth between the NAV
SRC and currently selected SRC.
Press and hold the NAV-button to adjust the monitor display settings. Adjust
brightness and contrast by rotating the rotary encoder (refer to “Picture
Adjustment” for further information).
5. TFT Display
6. Rotary Encoder
Rotate to adjust the volume. Press momentarily to activate the MUTE function.
Press again to resume normal listening.
7. USB/SD Interface Connector
Connect a USB device or insert an SD card for playback of music/video les.
8. A/V Input
Attach a compatible A/V device.
9. RESET
Press to reset system settings to factory default (except password and parental
lock settings).
72
