EXTERNAL DEVICES
Connecting External Devices
External devices, including a game console, camcorder, navigation unit, iPod®, Zune®, etc. can
be connected to this unit using its front A/V input 3.5mm jack (AV-In1), the rear RCA inputs (AV-
In2) or the USB port.
You cannot directly control external devices connected to the A/V INPUTs using the front panel
controls or this unit’s remote control.
AV-In1
AV-In1 is used for playback of audio/video from an external device connected to the unit through
a 3.5mm jack. The unit can increase or decrease the volume of the connected device all other
controls are done on the connected device. Select “AV-In 1” mode to access auxiliary devices.
AV-In2
AV-In2 is used for playback of audio/video from an external device connected through RCA
connectors located on the back of the unit (see the VXE 7020 NAV Installation Guide). The unit
can increase or decrease the volume of the connected device; all other controls are done on the
connected device. Select “AV-In2” mode to access auxiliary devices.
VXE 7020 NAV
AV INPUT
OPEN
3.5 mm A/V Cable (not included)
Video
RightAudio
LeftAudio
Ground
1
2
3
4
USB Cable (not included)
Connecting External Devices
78
