Audison AP 1 User Manual

29
Owner’s Manual
A
A
E F
A
3
A3
A D
B
C
A A
3
B C D E F U V V
1
V
2
AP 2 MV
without adapter
58,4 69,5 51 37 33,5 - - 64
-
3,5 4,5 mm
2.3 2.74 2.01 1.46 1.32 - - 2.52
-
0.14 0.18 in.
AP 4
102 130 93 43 41 150 26 117
-
7 5 mm
4 5.12 3.66 1.7 1.62 5.9 1.09 4.6
-
0.27 0.2 in.
AP 5
130 150 119 51,5 48,5 174 28 134,5
-
8,1 5,2 mm
5.12 5.9 4.68 2.03 1.9 6.85 1.1 5.3
-
0.32 0.2 in
AP 6.5
165 - 141 60 56 193 30 156
5
- - mm
6.5 - 5.55 2.36 2.2 7.6 1.18 6.14
0.2
- - in.
AP 6.5P
165 - 141 75 66,5 193 30 156
5
- - mm
6.5 - 5.55 2.95 2.62 7.6 1.18 6.14
0.2
- - in.
AP 6.5 C2
AP 6.5 Ω2
165 - 141 77,3 58,5 193 30 156
5
- - mm
6.5 - 5.55 3.04 2.3 7.6 1.18 6.14
0.2
- - in.
AP 8
209 - 174 70 66 234 26 196
-
8 5 mm
8.23 - 6.85 2.75 2.6 9.21 1.02 7.71
-
0.31 0.2 in.
APX 4
102 130 93 43 41 150 26 117
-
7 5 mm
4 5.12 3.66 1.7 1.62 5.9 1.09 4.6
-
0.27 0.2 in
APX 5
130 150 119 51 48 174 28 134,5
-
8,1 5,2 mm
5.12 5.9 4.68 2 1.89 6.85 1.1 5.3
-
0.32 0.2 in
APX 6.5
165 - 141 61 57 193 30 156
5
- - mm
6.5 - 5.55 2.4 2.24 7.6 1.18 6.14
0.2
- - in
V
U
/ Размер / 尺寸尺寸 / 规格规格 / Veličina / Velikost / Størrelse / Afmetingen / Size /
Suurus / Koko / Dimensions / Größe / Διαστάσεις / / Méretek / Ukuran /
Ingombro /
サイズサイズ / 크기크기 / Izmērs / Dydis / Størrelse / / Wielkość / Dimensão /
Dimensiuni /
РазмерРазмер / Rozmery / Velikost / Tamaño / Storlek / ขนาดขนาด / Ebat
V1
V2
AP 2 MV - AP 4 - AP 5 - AP 6.5 - AP 6.5P - AP 6.5 C2
AP 6.5 Ω2 - AP 8 - APX 4 - APX 5 - APX 6.5
Esec_JBL007_Owner's manual Prima Speaker_Rev 20D.indd 29Esec_JBL007_Owner's manual Prima Speaker_Rev 20D.indd 29 31/07/20 11:5831/07/20 11:58

Audison AP 1 Specifications
