Audison AP 1 - APK Series Wiring Diagrams; APK 165;130, APK 570, APK 690 Wiring

37
Owner’s Manual
AP 1
AP 6.5 / AP 5
AMP
APCX TW
800 mm
300 mm
APK 165 / 130
0
+ 2
0 dB
+2 dB
APCX TW 570
AP 1
AP 570
AMP
APCX TW 570
800 mm
300 mm
Car
Display
0
+ 3
0 dB
+3 dB
APCX TW 690
AP 1
AP 690
AMP
APCX TW 690
800 mm
300 mm
Car
Display
APK 570
APK 690
