Congratulations on purchasing our product. Your satisfaction is the rst requirement that our products must meet: the same
satisfaction as the one gained by those who long for experiencing the car audio emotion. This manual has been drawn to provide
the main instructions required to install and use the system properly. However, the range of possible applications is wide; for further
information, please feel free to contact your trusted dealer or our technical support at the email support@elettromedia.it Before
installing the components, please carefully read all of the instructions contained in this manual. Failure to respect these instructions
may cause unintentional harm or damage to the product.
1. All components must be rmly secured to the vehicle structure. Do the same when installing any custom structures
you may have built. Conrm your installation is solid and safe. A component coming loose while driving may cause serious
damage to the passengers, as well as to other vehicles.
2. Always wear protective eyewear when using tools, as splints or product residue may become airborne.
3. In order to avoid incidental damage, keep the product in the original packaging until you are ready for the nal installation.
4. Do not carry out any installation inside the engine compartment.
5. Before starting with the installation turn the head unit and all other audio system devices off, avoiding any possible damage.
6. Make sure that the location you choose to install the components does not interfere with the normal operation of any
mechanical or electrical devices of the vehicle.
7. Do not install loudspeakers where they may be exposed to water, excessive humidity, dust or dirt.
8. Do not install the components or make cable run close to electronic or mechanical devices of the vehicle.
9. Be very cautious when drilling or cutting into the vehicle chassis, making sure there are no cables or structural elements
essential to the vehicle underneath or in the selected area.
10. When routing cables, make sure that the cable does not come in contact with sharp edges or near moving mechanical
devices. Make sure that it is rmly attached and protected along its entire length and its insulation is self-extinguishing.
11. Only use cables with the proper section (AWG) indicated herein.
12. When running the cable through a hole in the vehicles chassis, protect the cable with a rubber ring (grommet). Be sure to
provide proper protection for cables running close to heat-generating devices.
13. Do not run the wires outside of the vehicle.
14. Use top quality cables, connectors and accessories such as found in the Connection catalogue.
15. Make sure your car has 12 VDC voltage negative ground electric system.
16. Check your alternator and battery condition to ensure they can handle the increased consumption.
17. The amplier can reach temperatures of around 80°C (176°F). Make sure it is not dangerously hot before touching it.
18. Periodically clean the amplier without using aggressive solvents that might damage it. Don’t use compressed air, since it
would push solid parts in the ampliers. Dampen a piece of cloth with water and soap, wring it and clean the amplier.
Then use a piece of cloth dampened with water only; eventually clean the amplier with a dry piece of cloth.
19. Pre-plan the conguration of your new amplier and the best wiring routes to ease installation.
20. Using a cable with adequate AWG (see chart: Power Supply Cable) , run the power wire from the battery location to the
amplier mounting location.
21. Connect the power supply with the correct polarity. connect (+) terminal to the cable coming from the battery and (-)
terminal to the car chassis.
22. Put an insulated fuse holder 40 cm max far from the battery positive terminal; connect one end of the power cable to it
after connecting the other end to the amplier.
23. To ground the device (-) in the right way, use a screw in the vehicle chassis; scrape all paint or grease from the metal
if necessary, checking with a tester that there is continuity between the battery negative terminal (-) and the xing point. If
possible, connect all components to the same ground point; this solution rejects most noise which can be generated during
the audio reproduction.
24. Route all signal cables close together and away from power cables.
25. Connect the RCA input cables, the applied signal must be between 0.3 V RMS and 5 V RMS.
26. Connect the high level inputs using the proper plug. Applied signal must be between 1 V RMS and 22 V RMS. Don’t use it if
you are already using Pre In preamplied connection.
27. Connect the speaker output using 10 AWG max speaker cable.
28. The amplier starts by connecting the remote turn on terminal to the source specic output. It starts automatically, without
remote signal, also if using high level inputs (Speaker IN) by setting the switch that can be found on the “Hi-IN AUTO TURN ON”
front panel to position ON.
29. When installation is over, check the system’s wiring and make sure all connections were done in the right way.
30. Put the fuse into the fuse holder. The fuse value will have to be 30% higher than the amplier built-in one. In case the cable
supplies several ampliers, the fuse value will have to be 30% higher than the sum of the values of all other fuses in the
ampliers.
31. Listening level calibration is made by adjusting the source volume up to ¾ of its maximum level; then, adjust the amplier
levels until you hear distortion.
32. Warranty certicate: For more information visit the Audison website.
SAFE SOUND
USE COMMON SENSE AND PRACTICE SAFE SOUND. PLEASE REMEMBER THAT LONG EXPOSURE TO EXCESSIVELY HIGH
SOUND PRESSURE LEVELS MAY DAMAGE YOUR HEARING. SAFETY MUST BE AT THE FOREFRONT WHILE DRIVING.
Information on electrical and electronic equipment waste (for those European countries which organize the separate collection of waste)
Products which are marked with a wheeled bin with an X through it can not be disposed of together with ordinary domestic waste. These electrical and
electronic products must be recycled in proper facilities, capable of managing the disposal of these products and components. In order to know where and how
to deliver these products to the nearest recycling/disposal site please contact your local municipal ofce. Recycling and disposing of waste in a proper way
contributes to the protection of the environment and to prevent harmful effects on health.
