Bevel gearboxes GK 10.2 – GK 40.2 Operation instructions
Gearbox SA/SAR 07.5-F10/G0 SA/SAR 10.1-F10/G0 SA/SAR 14.1-F14/G½
Bolt Lock washer Pcs. Bolt Lock washer Pcs. Bolt Lock washer Pcs.
GK 10.2
M10 x 25 B 10 4 M10 x 25 B 10 4 M16 x 40 B 16 4
GK 14.2
M10 x 25 B 10 4 M16 x 40 B 16 4
GK 14.6
M10 x 25 B 10 4 M16 x 40 B 16 4
GK 16.2
M16 x 40 B 16 4
GK 25.2
M16 x 40 B 16 4
Gearbox SA/SAR 14.5-F14/G½ SA/SAR 16.1-F16/G3 SA/SAR 25.1-F25/G4
Bolt Lock washer Pcs. Bolt Lock washer Pcs. Bolt Lock washer Pcs.
GK 16.2
M16 x 40 B 16 4
GK 25.2
M16 x 40 B 16 4
GK 30.2
M16 x 40 B 16 4 M20 x 50 B 20 4
GK 35.2
M16 x 40 B 16 4 M20 x 50 B 20 4
GK 40.2
M20 x 50 B 20 4 M16 x 50 B 16 8
Table 1: Bolts for mounting AUMA multi-turn actuators on bevel gearboxes
