Configuration of analogue inputs of the main valve
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Analogue inputs M0389
Example
Use input AIN1 for Setpoint position signal:
Parameter: Signal AIN 1 M0135
Setting value: Setpoint position (Wiring diagram designation:AIN 1 SETPOINT)
Use input AIN2 for Syn. link Position In signal:
Parameter: Signal AIN 2 M0138
Setting value: Syn. link Position In (Wiring diagram designation: ELSH In)
Configuration of analogue input of the main valve
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Analogue outputs M0335
Output AOUT 1 for Speed target value signal:
Parameter: Signal AOUT 1 M0131
Setting value: Speed target value (Wiring diagram designation:SPEED SETPOINT)
Configuration of analogue input of the secondary valve
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Analogue inputs M0389
Example
Use input AIN1 for Setpoint position signal:
Parameter: Signal AIN 1 M0135
Setting value: Setpoint position (Wiring diagram designation:AIN 1 SETPOINT)
8.10.1. Synchronous link function: activate
Required user level: Specialist (4) or higher.
Device configuration M0053
Application functions M0178
Activation M0212
Synchronous link M1789
Default value: Function not active
Setting values:
Function not active
<Synchronous link> function deactivated.
Function active
<Synchronous link> function activated.
8.10.2. Role (master actuator/slave actuator): define
Actuator controls configuration.
Customer settings M0041
Synchronous link M1791
Role synchr. link conn. M1792
Default value: MA master actu./rotat.
70
Actuator controls
Application functions ACV 01.2/ACVExC 01.2
