Selecting proper location for temperature
controller
Controller location largely affects its proper operation. When located
in a place without air circulation or exposed to direct sunlight, the
controller may not control the temperature properly. The controller
should be located on an internal wall of a building (partition wall) in
a place with free air circulation. Avoid locations near sources of heat
(TV set, heater, refrigerator) or places exposed to direct sunlight.
Location near doors and the resultant vibration may cause the
controller to function improperly.
Wiring your AURATON 3021
To connect the wiring, remove the enclosure as described below:
Wiring terminals are located in the controller back wall, under
the plastic cover.
cover
screw
1. 2.
