Mounting of AURATON Auriga – daily, hard-wired temperature regulator
In order to fix AURATON Auriga regulator to the wall, it is necessary yo:
Remove the housing (in the way shown in chapter “Connecting the cables to AURATON Auriga”).1.
Drill two holes of 6 mm diameter in the wall (the spacing of the holes should be determined by2.
the rear part of the regulator housing).
Insert the wall plugs into the drilled holes.3.
Screw the rear part of the regulator housing to the wall using the screws provided.4.
Put on the regulator housing.5.
NOTE:
In the case of a wooden wall, there is no need to use wall plugs. It is enough to drill
holes with a diameter of 2.7 mm (instead of 6 mm) and screw the screws directly into
the wood.
1 – Holes for fixing screws
