Auriol 4-LD5370 - Radio Outdoor Sensor Components and Connections

- 4 -
1 Indoor temperature 2 Ventilation recommendation
3 Indoor humidity 4 Mould warning
5 Alarm symbol 6 Time zone
7 SNOOZE/LIGHT-button 8 Time
9 Battery low indicator for station 10 Radio control symbol
11 Ventilation rating 12 Radio outdoor sensor channel
13
Battery low indicator for
radio
outdoor sensor
14 Radio outdoor sensor humidity
15
Radio o
utdoor sensor
temperature
16
CH- / up-button
17
MEM-/ down -button
18 °C/°F/SET-button
19 ON/OFF/ALARM-button 20 Comfort display
21 Hole for wall mounting 22 Ventilation slots
23 Battery compartment 24 Folding Stand
25 Buzzer 26 RESET-button
Radio outdoor sensor
