8-4
TECHNICAL SPECIFICATION
WEIGHT AND DIMENSION DATA (continued)
DIMENSIONAL DATA
MODEL LANCASHIRE EK ES EL
(Data for standard roof version) Low Profile Overcab Low Profile
Base Vehicle Manufacturer Peugeot Peugeot Peugeot
Base Vehicle Model 333 L1 335 L1 333 L1
Wheelbase 3000 3000 3000
METRIC DIMENSIONS (mm)
Overall Length 5630 5630 5630
Overall Width (mirrors extended) 2690 2690 2690
Overall Width (mirrors folded) 2320 2320 2320
Overall Height 2900 3005 2900
Internal Height (maximum) 1960 1960 1960
Internal Height (minimum) 1920 1920 1920
Double bed, transverse 2100 x 1400 2100 x 1380 tba
Single bed, nearside 1850 x 700 1850 x 550 tba
Single bed, offside 1750 x 700 1750 x 620 tba
Overcab bed n/a 1900 x 1300 n/a
Fresh water tank capacity (litres) 102 102 102
Waste water tank capacity (litres) 71 71 71
Gas bottles, Butane 1 x 15 + 1 x 7 kg 1 x 15 + 1 x 7 kg 1 x 15 + 1 x 7 kg
Gas bottles, Propane 1 x 13 + 1 x 6 kg 1 x 13 + 1 x 6 kg 1 x 13 + 1 x 6 kg
