Operation Instructions
Multi-Function Controller
1) Stop
2)Up
3) Down
The multi-function remote operates with RF (Radio Frequency)
and IR (Infrared) simultaneously.
1)
Stop - Press and release for stop motion
2)
Down – Press and release for down motion
3)
Up – Press and release for up motion
Additional Button Functions:
A) When in motion, press the opposite direction.
The lift will pause for 1 second and then reverse direction.
B) When in motion, press the same button direction.
The lift will stop.
Optional Control Method
Connect optional control accessory
to AUX port
IR Control
Connect the IR eye to the EYE port
Dry Contact Operation:
Short desired operation with COM
